Content: see parts list

resistance 10^6 to 10^7 ohm (back side 10^3 to 10^4 ohm)

especially for CPUs (central processing units), printers, scanners

table mat with 2 press buttons 10 mm for ground connection

ESD earthing plug 2 x 1 MOhm and M5 connection and 1.8 m ground cable 2 push buttons 10 mm

ESD mat for table, shelf or floor, extremely wear-resistant, permanently elastic

also for solder-resistant workplace pad, heat resistant, abrasion resistant, scratch proof

Platinum gray on top, black back of electrostatically dissipative synthetic rubber, Halogen free

measures 610 x 450 x 2 mm

weight 792 g

The grounding mat as a safe method to dissipate electrostatic charge, suitable for table, shelf or floor.

Products meet the requirements of DIN EN 61340-5-1. Specifications of the mat: Abrasion (load: 5N) 130 mm³, hardness 78 Shore A, impression test 0.1 mm, light reflectance 19% - 29%, temperature range of application up to + 60°C.

ESD handling set consists of: 9-367-0 ESD grounding mat grey 610x450x2 mm;9-359-2 ESD earth bonding plug 2x10 mm and M5 socket;9-343-1 ESD grounding cable 1 MOhms, 1800 mm 2 press-studs 10/10 mm

Marke: Bernstein Tools for Electronics

EAN: 4250838511773
