dissipative ESD handle with rotating cap (conductance 10^5 to 10^7 Ohm)

blade length 60 mm

blade Ø 6.8 mm

blade width 5.0 mm

Blades material chrome-vanadium-molybdenum steel, matt chrome

tip matt chrome, manufactured according to DIN ISO

length 160 mm

weight 32 g

For all work on electrostatically sensitive components. The blades are made of quality steel to ensure torsion resistance - at maximum stress. The tips are burnished for dimensional stability and to prevent chrome chipping (except sockets). The rotating cap is smooth-running and allows the screwdriver to be held in position despite starting pressure. Thanks to the ergonomically shaped handle, the screwdriver fits perfectly in the hand.

The ergonomic handle of the screwdriver is made of ESD plastic (PP black) and has a surface resistance of 10^5 to 10^7 Ohm. The matt chrome-plated blade is made of high-quality chrome-molybdenum steel (hardness greater than 55 HRC) according to DIN ISO and is hardened over its entire length.

Marke: Bernstein Tools for Electronics

EAN: 4250838507547
