Trimmer for easy and safe setting of spindle resistances and potentiometers (Poti)

ESD handle with rotating cap dissipative between 10^6 and 10^9 ohm

blade length 20 mm

blade Ø 3 mm

blade PH 00

material zirconium oxide, technical ceramic

antimagnetic

length 100 mm

weight 10 g

Adjustment tools for the ESD area. Ceramic bits meet the highest requirements due to their excellent mechanical, thermal properties. The hardness and breaking strength of zirconium oxide enable the manufacture and use of even the smallest dimensions with the greatest possible wear resistance. Adjustment tools in use, a variety of electrical and electronic equipment or assemblies must be aligned or adjusted after the manufacturing process. Even when installing new components or when electrical values have changed due to aging, an adjustment is usually necessary to restore the optimal device function. For the different application areas we offer adjustment tools made of different materials. In the field of ceramics, we manufacture not only many standard blades but also special shapes on customer request. Contact us and we will assist you with the implementation of your ideas.

Zirconium oxide is a highly wear-resistant ceramic (zirconium), tetragonal ZrO2, Y2O3, partially stabilized. Physical properties at room temperature: flexural strength 800N/mm², modulus of elasticity 2x105N/mm², density 6.05g/cm³, hardness 1350HV, application range up to 800°C, coefficient of thermal expansion 10x10-6 K-1, thermal conductivity 2W/mK, electrical resistance insulated.

1-765 ceramic blade (Bit) cross-recess PH00

Marke: Bernstein Tools for Electronics

EAN: 4250838501293
